Part 1: Printer Settings

Choose the settings below that match your specific printer model.

OPTION A: i650 Print Optimizer Settings

1. Open your graphic in the UNDERPRINT tab.
2. Under Printer Options, set Media Type to User Type 2.
3. Set Media Weight to Ultra Heavy 2.

OPTION B: i560 Print Optimizer Settings

1. Open your graphic in the UNDERPRINT tab.
2. Under Printer Options, set Paper Type to Labels.

OPTION C: 8432 and 9541 Print Optimizer Settings

1. Layer Profile: Remove the checkmark next to "White" (turn white toner OFF) and check "No Mirror".
   *Note: If your queue automatically mirrors designs, you must uncheck it on the main screen (see Step 3 below).

2. Printer Options: Set Media Type to Glossy and Media Weight to Ultra Heavy 2.
