APPLICATION TIPS
Pre-Press Shirt
To remove moisture and bring
the shirt to the correct pressing
temperature it is critical that the shirt
is pre-pressed prior to applying the
transfer.
Pressure
TrimFree, as with all transfer papers
for light shirts, requires Maximum
pressure. Using maximum pressure
will ensure the transfer paper will peel
correctly and increase the washability
of the design.
Peeling
It is important to wait 7 to 10 seconds
prior to peeling the transfer. Do not
remove the shirt from the press prior
to peeling, doing so will cause the
transfer to cool too quickly making the
transfer difficult to peel.
When peeling, use a slow and consistent motion.
DO NOT Cover your transfer with Teflon when pressing TrimFree.
Fabric Types - 7 to 10 Second Wait Time
TrimFree will work well on cotton,
cotton blends and polyester. Most
t-shirt fabrics only require a 7 second
wait period prior to peeling, heavier
fabrics such as sweat shirt material
usually require the full 10 seconds.
Because there is such a wide variety
to different fabrics we suggest you
test your material to determine the
best wait time.
Paper Mode
For the fuser to properly fuse the
toner to the paper we suggest using
Heavy Paper or Label Mode. You
may need to test 2 or 3 different
settings to find the best setting for
your printer. To check for good toner
adhesion, run your finger across the
printed image. If any toner transfers
to your finger you should set your
paper mode setting on your print
driver to a heavier setting.
Loading and Exit Tray
TrimFree should be printed using
the by-pass tray. If your printer has
a rear exit door that will allow the
paper to exit straight out the back we
suggest you test the paper using this
configuration.
Suitable Graphics
TrimFree works best with graphics and
designs that have solid colors such as
corporate logos or plain type.
TrimFree is best suited for logos or
graphics, if you are printing large
square images or photographs we
suggest using CL 135.
Printers/Copiers Tested
OKI DATA: Recommended
CANON: Recommened
XEROX: Recommended
SAMSUNG: Recommended
RICOH: Recommended
HP: Not Recommended
BROTHER: Not Recommended
Although testing has been done on the above
brands of printers, it is recommended that
you do your own testing due to the many
different models in the market.
Call Today 800-891-1094 or Contact Support Service!
CL-TrimFree-1StepAPPLICATION INSTRUCTIONS
Step By Step
Step 1 Feed material into laser printer so that the printer is printing on the printable side (white matte coated side). Step 2 Design your image and and resize if necessary. Step 3 Prepress fabric for 5-10 seconds. Step 4 Place imaged CL TrimFree on fabric with image face down. Step 5 Heat apply the transfer onto the shirt. Press at 330-340F at 25-30 seconds. Use maximum pressure. Step 6 Do not remove fabric from heat press. Peel transfer off warm. Wait approximately 7-10 seconds before peeling. Step 7 Repress imaged t-shirt for 30 seconds at 330F using enclosed silicon sheet. This will seal the coating to allow better wash resistance.APPLICATION
Printer: Laser Non-Oil Recommended Paper Mode: Heavy or Label mode Image: Mirror Press Time: 25-30 sec. Temperature: 330-340F (165-170C) Pressure: Maximum Peel: Warm (wait 7-10 seconds) Wash Temp.: Up to 105F (40C )
* All technical information and recommendations are based on tests we have conducted. Users should conduct their own tests before proceeding.
NOTES
Recommended Fabrics White or Light Colored 100% cotton 100% polyester Poly/cotton blends Polyester knits Polyester mesh Poly/foam & cotton caps Satin Accessories Required Computer, Color Laser Printer, Heat Press. Printable side The printable side is the white matte Coated side. Care Instructions Wait 24 hours before washing. Machine wash using mild detergent. Do not use bleach or other aggressive cleaning agents. Cannot be dry cleaned. Wash Temperature cannot exceed 105F. Pressure Settings To ensure that the coating has properly fused with the fabric, we recommend to use maximum pressure. If this paper is applied with inadequate pressure, the transfer will not wash well. Peeling This paper is to be peeled warm. Peeling should occur 7-10 seconds after pressing. Also if you have difficulties peeling the backing off the shirt, while the fabric is hot, gently tug on the sides of the shirt, the backing will "pop" right out. Depending on fabric and toner coverage, wait time before peeling will vary. Test before commerical production. Storage CL TrimFree has an indefinite shelf life when stored at room temperature. Keep away from direct heat, sunlight and humidity.Call Today 800-891-1094 or Contact Support Service!
CL-TrimFree-1Step (FOR USE WITH FOIL)APPLICATION INSTRUCTIONS (1 OF 2)
Step By Step
Step 1 Feed material into laser printer so that the printer is printing on the printable side (white matte coated side). Step 2 It is recommended to use black only when doing foil. Design your black only image and and resize if necessary Step 3 Prepress fabric for 5-10 seconds. Step 4 Place imaged CL TrimFree on fabric with image face down. Step 5 Heat apply the transfer onto the shirt. Press at 330-340F at 25-30 seconds. Use maximum pressure. Step 6 Do not remove fabric from heat press. Peel transfer off warm. Wait approximately 7-10 seconds before peeling.APPLICATION
Printer: Laser Non-Oil Recommended Paper Mode: Heavy or Label mode Image: Mirror Press Time: 25-30 sec. Temperature: 330-340F (165-170C) Pressure: Maximum Peel: Warm (wait 7-10 seconds) Wash Temp.: Up to 105F (40C )
* All technical information and recommendations are based on tests we have conducted. Users should conduct their own tests before proceeding.
NOTES
Recommended Fabrics White, Light, or Dark colored: 100% cotton 100% polyester Poly/cotton blends Polyester knits Polyester mesh Poly/foam & cotton caps Satin Accessories Required Computer, Color Laser Printer, Heat Press. Printable side The printable side is the white matte Coated side. Care Instructions Wait 24 hours before washing. Machine wash using mild detergent. Do not use bleach or other aggressive cleaning agents. Cannot be dry cleaned. Wash Temperature cannot exceed 105F. Pressure Settings To ensure that the coating has properly fused with the fabric, we recommend to use maximum pressure. If this paper is applied with inadequate pressure, the transfer will not wash well. Peeling This paper is to be peeled warm. Peeling should occur 7-10 seconds after pressing. Also if you have difficulties peeling the backing off the shirt, while the fabric is hot, gently tug on the sides of the shirt, the backing will "pop" right out. Depending on fabric and toner coverage, wait time before peeling will vary. Test before commerical production. Storage CL TrimFree has an indefinite shelf life when stored at room temperature. Keep away from direct heat, sunlight and humidity.ADDITIONAL APPLICATION INSTRUCTIONS, SEE PAGE BELOW
Call Today 800-891-1094 or Contact Support Service!
CL-TrimFree-1Step (FOR USE WITH FOIL)APPLICATION INSTRUCTIONS (2 OF 2)
Step By Step
Step 7 Once you have pressed your TrimFree image onto fabric, place foil on top of the transfer with colored side face up. Step 8 Press at 330-340F at 25-30 seconds. Use maximum pressure. Step 9 Carefully peel the foil off cold using a consistent and smooth motion. Step 10 Repress imaged t-shirt for 30 seconds at 330F using enclosed silicon sheet. This will seal the foil to allow better wash resistance.APPLICATION
Application: Foil Fabric Color: White, Light, or Dark colored Fabrics Recommended image: All black Press Time: 25-30 sec. Temperature: 330-340F (165-170C) Pressure: Maximum Peel: Cold Wash Temp.: Up to 105F (40C )
* All technical information and recommendations are based on tests we have conducted. Users should conduct their own tests before proceeding.
